Introduction

As our customers aimed to migrate their Ubuntu-based virtual machines from Azure to AWS EC2 to reduce costs and enhance operational flexibility, ensuring a smooth and reliable cloud migration process was essential. Any downtime or data inconsistency could significantly impact business continuity.

As a trusted cloud consulting company, we recommended leveraging AWS Application Migration Service (MGN) to carry out the migration with minimal downtime and risk. AWS MGN enabled a streamlined and efficient transfer of Ubuntu VMs from Azure to AWS, ensuring consistency, speed, and reliability throughout the process.

This blog walks you through the step-by-step approach of using AWS MGN for cloud migration, detailing the prerequisites, configuration, and technical steps involved in achieving a seamless transition to the AWS cloud.

Prerequisites

Before starting the migration process, ensure the following:

• Disable secure boot and vTPM in the source Azure VM
• Create an IAM user in AWS with the necessary policies:

AWSApplicationMigrationAgentInstallationPolicy, AWSApplicationMigrationAgentPolicy

• Generate access and secret keys for the IAM user, which will be used to install the replication agent in the Azure VM

• Ensure that the Azure VM has internet access (public IP or through NAT)

Handling EC2 Status Check Failure

If the steps outlined in this guide are not followed correctly, you may encounter an issue where the status check fails when launching the EC2 instance. This typically happens because the migrated VM is still using Azure-specific settings, such as the wrong kernel or cloud-init configuration.

When the Azure-specific kernel or services are still active, the EC2 instance may fail to boot properly in the AWS environment, resulting in a Status Check Failed error. To avoid this issue, follow the migration steps.

Migration Steps

1. Prepare the Azure VM:

• Connect to the Azure VM via SSH.
• Verify the running kernel

uname -r

• Enable root password authentication for troubleshooting.

sudo passwd root

2. Install AWS Replication Agent on Azure VM:

• Update the GCC compiler if the replication agent is not getting installed

sudo apt-get update

sudo apt-get install gcc-12

sudo update-alternatives –install /usr/bin/gcc gcc /usr/bin/gcc-12 12

sudo update-alternatives –config gcc

sudo apt-get install linux-headers-$(uname -r)

• In the AWS MGN console, In source server click on add server and select the linux machine option
• Provide the IAM access key ID  and secret access key
• Download the installer using the below command

sudo wget -O ./aws-replication-installer-init

“https://aws-application-migration-service-ap-south-1.s3.ap-south-1.amazonaws.com/latest/linux/aws-replication-installer-init”

3. Install AWS Linux Kernel:

• Install the AWS-tuned kernel

sudo apt install linux-aws

• Verify the kernel installation

dpkg –list | grep linux-image

• Update the system to boot from the AWS kernel. (Do not reboot the machine)

sudo vim /etc/default/grub

By default GRUB_DEFAULT value will be 0. Update it with the AWS kernel.

GRUB_DEFAULT=”Advanced options for Ubuntu>Ubuntu, with Linux 6.5.0-1024-aws” (update the version based on the aws kernel version installed in the source VM)

• Important: Do not reboot the VM at this point, as a reboot will apply the kernel changes on the source VM, which could cause the Azure VM to enter a generalized state

4. Disable Azure Services (Since azure services are not supported by aws ec2)

• Identify running Azure-native services

systemctl –type=service

• Disable unnecessary Azure services if it is running.

sudo systemctl disable hv-kvp-daemon.service

sudo systemctl disable walinuxagent.service

sudo systemctl disable walinux-agent-network-setup.service

5. Reconfigure Cloud-Init Data Source

• Change the data source to AWS EC2

dpkg-reconfigure cloud-init

Select the “EC2: read data from EC2 metadata service” option by clicking the space bar and unselect the azure option and press the tab and click enter

6. Start Replication Process

• Execute this command in the Azure VM to begin the replication

sudo chmod +x aws-replication-installer-init; sudo ./aws-replication-installer-init –region –aws-access-key-id –aws-secret-access-key –no-prompt

: Replace this with your AWS region (e.g., us-west-2, ap-south-1)

: Replace this with the IAM Access Key ID

: Replace this with the IAM Secret Access Key

7. Launch Test Instance:

• After completing the replication we can see the  azure VM in the source server section of the MGN console
• Click on the azure VM in the MGN console and create a launch template and update the version of launch template from the EC2 service launch template section
• Access the test instance
• The default SSH username and private key will remain the same as the source Azure VM. Even if a new key is attached to the EC2 instance during launch, it will not take effect
• Therefore, update the public key to match the private key that you want to use with the target EC2 instance
• ssh-keygen -y -f /path/to/new-key.pem
• Copy the output and add it to ~/.ssh/authorized_keys on the target ec2 instance

8. Final Steps

• Reboot the instance
• After rebooting, you will be able to SSH into the migrated instance
